| Model | FLA48200 |
| Energy | 10Kwh |
| Battery Type | LiFePO4 |
| Nominal Voltage | 51.2V |
| Operating Voltage | 44.8-57.6V |
| Recommend Charge/Discharge Current[1] | ≤120A |
| Recommend Charge/Discharge Power[1] | ≤6000W |
| Maximum Charge/Discharge Current(15s) | 150A |
| Maximum Charge/Discharge Power(15s) | 7500W |
| Depth of Discharge(DOD) | ≥95% |
| Scalability | Up to 15 units in parallel(150Kwh) |
| Communication | RS485/CAN |
| Protection Level | IP21 |
| Cycle Life[2] | ≥6,000 Cycles |
| Charging Temperature Range | 0-55℃ |
| Discharging TemperatureRange | -20-55C |
| Display | LCD+LED |
| Installation | Wall-Mounted/Floor-Mounted |
| Protection | Built-in smart BMS, Breaker, Fuse |
| Warranty | 7 Years |
| Net Weight | 68KG |
| Gross Weight | 88KG |
| Product Dimension | 735*433*188MM |
| Package Dimension | 815*552*362MM |
| [1]Recommend charge/discharge current/power is affected by temperature and SOC. | |
| [2] Test conditions:0.2CCharging/Discharging @25°C,80% DOD | |
